Intel® Optane Memory ReadyĬhipset: 6 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)ġ x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x M.2 Socket 3 connector 6 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.1 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2圆 pin, for the GC-TPM2.0_S module only) 1 x parallel port header 1 x serial port header 1 x Clear CMOS jumperġ x PS/2 keyboard/mouse port 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 4 x USB 3.1 Gen 1 ports 2 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks 1 x PCI Express x16 slot, running at x4 (PCIEX4) 2 x PCI Express x1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.)Ĭhipset: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) 6 x SATA 6Gb/s connectors * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
Gigabyte b360m ds3h lga 1151 matx install#
Realtek® ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.ġ x PCI Express x16 slot, running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
Support for up to 3 displays at the same time Maximum shared memory of 1 GB 1 x HDMI port, supporting a maximum resolution of Hz * Support for HDMI 1.4 version and HDCP 2.2. Integrated Graphics Processor-Intel® HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of Hz 1 x DVI-D port, supporting a maximum resolution of Hz * The DVI-D port does not support D-Sub connection by adapter.
(Please refer "Memory Support List" for more information.) Support for 8th Generation Intel® Core i7 processors/Intel® Core i5 processors/Intel® Core i3 processors/Intel® Pentium® processors/ Intel® Celeron® processors in the LGA1151 package 元 cache varies with CPU (Please refer "CPU Support List" for more information.)Ģ x DDR4 DIMM sockets supporting up to 32 GB of system memory Dual channel memory architecture Support for DDR4 2666/2400/2133 MHz memory modules Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules * To support 2666 MHz or XMP memory, you must install an 8th Generation Intel® Core i7/i5 processor. Ultra Durable 15KV Surge LAN Protection.Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP.CEC 2019 Ready, Save the Power as Easy as One Click.GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management.Ultra-Fast M.2 with PCIe Gen3 X4 & SATA interface.High Quality Audio Capacitors and Audio Noise Guard with LED Trace Path Lighting.Supports 8th Gen Intel® Core Processors.Intel B360 Ultra Durable motherboard with GIGABYTE 8118 Gaming LAN, PCIe Gen3 x4 M.2, Anti-Sulfur Resistor, Smart Fan 5, DualBIOS, CEC 2019 ready
